  • Hood Pad Installation Picture

    Could someone please send me a picture or point me to a picture of a correctly installed hood pad for my 55.
    Thanks
    Bill


    http://www.rustyrestorations.org/gal...d=61&g2_page=1
    http://www.rustyrestorations.org/index.php
    sigpic

  • #2
    Are you sure it had one originally? I probably just never looked that close, but I don't remember seeing a 55 with a hood insulation. I know this is no help.

    1952 Champion Starlight since October,1971. 1962 Daytona
    since May, 2007.Searcy,Arkansas
    "In the heart of Arkansas."
    Searcy, Arkansas
    1952 Commander 2 door. Really fine 259.
    1952 2R pickup

    Comment


    • #3
      The part # for it is 2033x2
      It is not centered on the hood but offset to the right and rear. You can see a little of it in the engine photo of Johannessen's car in the article in Collectible Automobile Oct. 1998
      Klif


      55 Speedster
      55 Speedster/Street Machine
      63 Avanti R2
      64 Convertible R1

      Comment


      • #4
        I just snapped some pics of the remains of the pad on the underside of the hood of my '55 coupe. will post later.

        nate

        --
        55 Commander Starlight
        http://members.cox.net/njnagel
        --
        55 Commander Starlight
        http://members.cox.net/njnagel

        Comment


        • #5
          Don't know if it was original or not but, when I bought my '53 Coupe in 1976 it had the insulation; also had a couple strips of wood (ash or poplar) 1/8" thick and 2 3/8" wide wedged laterally across the underside of the hood to retain the insulation. I never saw anything like that before and, assuming it wasn't original, someone went to a lot of trouble to make them look and fit correct.

          Just today I installed a new pad in my '53; intended to center it but got it just an inch or so to the passenger side.

          Brad Johnson
          Pine Grove Mills, Pa.
          '33 Rockne 10, '51 Commander Starlight, '53 Commander Starlight
          "All attempts to 'rise above the issue' are simply an excuse to avoid it profitably." --Dick Gregory

          Brad Johnson, SDC since 1975, ASC since 1990
          Pine Grove Mills, Pa.
          sigpic'33 Rockne 10, '51 Commander Starlight, '53 Commander Starlight "Désirée"

          Comment


          • #6
            you know, I just realized that the underside of my hood has obviously been repainted, as my car was originally blue. But here's the pics anyway, I think this is probably about the right location.

            http://members.cox.net/njnagel2/hoodpad/hoodpad.html

            nate

            --
            55 Commander Starlight
            http://members.cox.net/njnagel
            --
            55 Commander Starlight
            http://members.cox.net/njnagel

            Comment
